Hamilton Hartland G2 Antique Brass 1 Gang 20AX Intermediate Toggle Switch with Antique Brass Toggle
Hamilton Hartland G2 Antique Brass 1 Gang 20AX Intermediate Toggle Switch with Antique Brass Toggle
- Estimated delivery: 2 - 5 working days
- Free delivery: on orders over £95.00 to mainland UK
Hamilton Hartland G2 Antique Brass 1 Gang 20AX Intermediate Toggle Switch with Antique Brass Toggle
Hamilton Hartland G2 Antique Brass 1 Gang 20AX Intermediate Toggle Switch with Antique Brass Toggle
The Hamilton Hartland G2 range is an affordable collection of screwless switches and sockets featuring sleek round edges and push-to-fit face plates in six stylish finishes. All Hartland G2 wiring accessories are also covered by a 25 year guarantee for added peace of mind.
- Product range: Hartland G2
- Complete with high-quality gasket as standard
- Screwless push-to-fit front plate, designed with Hamilton's patented easy clip system
- Plate finish: Antique Brass
- Plate material: Metal
- Insert: Antique Brass Toggle
- Intermediate toggle switch
- Gangs: 1
- Current rating: 20 AX
- Voltage: 220/250 V AC
- Mains frequency: 50 Hz
- Maximum load: 20 Amps inductive
- Switched poles: Single
- Plate size: Single
- Plate width: 87.5 mm
- Plate height: 87.5 mm
- Plate depth: 4.65 mm
- Minimum wall box depth: 35 mm
- Contact gap minimum: 3 mm
- CE marked
- IP rating: IP2XD
- Ambient operating temperature: -5 to +40 °C
- Internal Use Only
- Maximum installation altitude: 2,000 m
- Guarantee: 25 years
- Must be earthed
- Terminal capacity:
- 5 x 1 mm²
- 4 x 1.5 mm²
- 2 x 2.5 mm²
- 2 x 4 mm² Multi-strand
- 1 x 6 mm²
- Earth terminal capacity:
- 6 x 1 mm²
- 5 x 1.5 mm²
- 3 x 2.5 mm²
- 2 x 4 mm² Multi-strand
- 1 x 6 mm²
- BS EN ISO standard(s): BS EN 60669-1
|
|
|---|---|
|
This product is IP20 rated |
|
|
|
Zone 0
Inside the bath or shower tray. Minimum IP rating of IP67, and a maximum voltage of 12 V.
Zone 1
Directly above the bath to a height 225 cm from the floor, or the inside of shower cubicle excluding the tray. Minimum IP rating of IP65.
Zone 2
60 cm perimeter around the bath or shower to a height 225 cm from the floor. 60 cm radius around sink tap. Minimum IP rating of IP44.
Zone 3
Anything outside the other zones. No IP rating requirements.
Description
- Gangs 1 Gang
- Product Plateswitch
- Switched/Unswitched Switched
- Type Toggle
- Ways Intermediate
Dimensions
- Depth 4.65 mm
- Fixing Centres 60.3 mm
- Height 87.4 mm
- Mounting Box Minimum Depth 35 mm
- Width 87.4 mm
Features
- Flex Outlet N
- FM/DAB N
- Fuse Fitted N
- Includes 13A Switch Socket? N
- Includes RCD? N
- Ingress Protection IP2XD
- Lockable? N
- Mounting Flush
- Neon Indicator N
- Pole Configuration Single Pole (1P)
- RJ11 N
- RJ45 Cat 5E N
- RJ45 Cat 6 N
- Satellite N
- Screwless? Y
- Telephone Master N
- Telephone Secondary N
- TV Socket N
- USB N
General
- CE Approved N
- Standards BS EN 60669-1
Material & Finish
- Body Material Metal
- Face Colour Antique Brass
- Rocker Colour Antique Brass
Technical Data
- Current Rating 20 A
- Voltage 220/250 V
